BPS, CPS, DPS Series

The Hydraulic Warehouse
Sale!
TheHydraulicWarehouse_hires

Pressurised breathers can reduce breathing by as much as 90% to 95%, increasing the life of the breather by a factor of 10. They are recommended for systems that are expected to operate in extremely dusty environments. Operates similar to a conventional breather except it incorporates a relief valve set at 5 or 10 psi and a vacuum breaker. When the level first falls, air enters the reservoir through the vacuum breaker and filter. When the level rises, air is compressed rather than being expelled. Therefore, changing fluid levels are accommodated by the changing size of the air bubble in the reservoir, instead of breathing to atmosphere.

Ordering Guide

The ordering guide below provides technical specifications to assist you with your selection. When you are ready to order, simply scroll down to the 'Place your Order' section below the Ordering Guide or click on a part number in the Ordering Guide table.

Part Number Micron Rating Airflow (m³/min) Thread Cap Diameter (mm)
BPS40B12A 40 0.57 G3/4 70
CPS40B12A 40 0.24 G3/4 57
DPS40B04A 40 0.07 G1/4 42
DPS40B06A 40 0.12 G3/8 42

All the above come fitted with anti-splash baffle.

Place your Order

To make a purchase, simply scroll down to your desired part number, enter your order quantity in the box provided and then click on the 'Add to cart' button to add the product to your shopping cart.

  • BPS40B12A

    Brand: The Hydraulic Warehouse
    List Price: $23.00 ex. GSTOur Price: $16.10 ex. GST
  • CPS40B12A

    Brand: The Hydraulic Warehouse
    List Price: $15.00 ex. GSTOur Price: $10.50 ex. GST
  • DPS40B04A

    Brand: The Hydraulic Warehouse
    List Price: $10.00 ex. GSTOur Price: $7.00 ex. GST
  • DPS40B06A

    Brand: The Hydraulic Warehouse
    List Price: $12.00 ex. GSTOur Price: $8.40 ex. GST
